WISA-Multiwall is a high quality and elastic lining panel for end uses where a good looking surface material with high resistance is needed. WISA-Multiwall has been developed for sidewalls of vehicles such as horse trailers and linings of vans but also shop fittings and interior linings. WISA-Multiwall is an ideal decorative material for the varied needs of the transport and construction industries.
WISA-Multiwall
Properties
- Decorative plastic coated panel
- Wear resistant
- Crack resistant surface
End-uses
- Van linings
- Trailers and other vehicle sidewalls
- Horse trailers
- Shop fittings
- Exterior and interior uses
Bonding
Phenolic resin cross-bonded base panel weather resistant gluing according to
EN 314-2/class 3. Gluing of coating EN 204 class D4.
Surface and edges
About 0.2 mm, slightly embossed polypropylene coating with lacquered surface.
Panel size
1200/1220/1250/1500/1525 x 2400/2440/2500/3000/3050 mm
Other sizes upon request.
Thicknesses and weights
| Nominal thickness (mm) | Number of plies | Thickness (mm) | Weight (kg/m2) |
|---|---|---|---|
| min. - max. | |||
| 6.5 | 5 | 6.6 - 7.4 | 4.8 |
| 9 | 7 | 9.3 - 10.0 | 6.5 |
| 12 | 9 | 12.0 - 13.0 | 8.6 |
| 15 | 11 | 14.8 - 15.6 | 10.6 |
| 18 | 13 | 17.4 - 18.4 | 12.6 |
| 21 | 15 | 20.3 - 21.2 | 14.7 |
| 24 | 17 | 23.2 -24.0 | 16.7 |
| 27 | 19 | 25.5 - 27.1 | 18.8 |
Moisture content 8-10 %.
